The term prefolder is a very encompassing term for any (press O.E.M. aftermarket) ribbon creating and positioning and/or parallel to web direction folding sequence prior to final cutoff and delivery of (most often) a press O.E.M. folder.
Global Web Finishing staff has as much experience as anyone in this market and sees prefolders as a great value add to many commercial, insert and publication presses. The product format opportunities from prefolders are huge - and for the limited investment cost, can’t be beat.
From a basic standpoint, GWF realizes that prefolders are looked at sometimes as a commodity purchase since nearly everyone who builds new web finishing machinery supplies prefolders. GWF’s clear advantage, however, is different.
First, GWF will quote a new or pre-owned machine, going as far as locating and supplying a pre-owned machine (when available) in a fully re-engineered condition as requested for often significant savings against new.
Next, our engineers are specialists in the finer points such as:
- Installation, support structures and accessibility
- Custom drives, controls and press integration
- Expert operational training and assistance 24/7/365
|
 |
Anyone will sell you machines. Very few, if any, offer professional services like GWF - and none will work as hard to meet your budget. It’s not much of a bargain if you try to run your first job and find it won’t go. The time, paper waste, contractual liabilities and lost customers can quickly wipe out the money you may have saved on the initial deal.
GWF is fully committed to providing you the best possible choices; not just with prefolders, but in everything we do.
GWF offers a complete variety of web press prefolders. From basic Ribbon Shifting of 1 web in 2 ribbons out, to as many webs in and out as one would need for a tabloid style Sunday newspaper.
From single gate Plow Folds running down the former of a combination folder, to a multi plow, mini inline/insert finishing system installed above the dryer/chills area and delivering into a press folder, floor mounted sheeter or rotary cutter. |
 |
The following is a list of GWF’s basic prefolder design offerings. GWF will customize any design to meet your needs.
- PF1 (single Plow Fold only) for 8, 16 or 24 page presses
- PF2 (2 consecutive Plow Folds only) for 8, 16 or 24 page presses
- RS11 (1in/1out) 90° turn Ribbon Shifting for 8, 16 or 24 page presses
- RS11f (1in/1out) web flopper Ribbon Shifting for 8, 16 or 24 page presses
- RS12 (1in/2out) Ribbon Shifting for 8, 16 or 24 page presses
- RS14 (1in/4out) Ribbon Shifting for 8, 16 or 24 page presses
- RS22 (2in/2out) Ribbon Shifting for (2x) 8, 16 or 24 page presses
- RS24 (2in/4out) Ribbon Shifting for (2x) 8, 16 or 24 page presses
- RS28 (2in/8out) Ribbon Shifting for (2x) 8, 16 or 24 page presses
- RSPF111 (1in/1out Ribbon Shifting w/single Plow Fold) positioned 90° from press CL for 16 page press delivery into DFF
- RSPF121 (1in/2out Ribbon Shifting w/single Plow Fold) for 8 or 16 page presses
|
 |
Standard features for GWF prefolders include:
- Heavy gauge solid side frames, cross spreaders and supports
- Chrome plated angle bars with motorized sidelay control
- Rotary style plow folders with necessary support rollers
- Motorized compensator for ribbon to ribbon registration control
- Driven draw rollers at both entry and exit sides of plow fold machines
- Pneumatic loaded nip trolleys on all driven draw rollers
- Hardened driven draw rollers at all crush slit locations
- Pneumatic loaded slitter trolleys on designated roller locations
- Independent drive motor system with HMI touch screen
- Each plow fold position includes two-stream plow fold assemblies
- Plow fold geometry will allow entire web width folded in half
- Adjustable fold hold rollers for proper fold creasing and stability
- All path rollers necessary to complete web paths in and out of machines
- Standard support structure on press for safe, rigid installation
Options for GWF prefolders can include:
- Two additional plow folder options including stationary “cone/shoe” type plows or “geometric/angle bar” type plow folders.
- Motorized plow folders in two or three streams
- Large 4” (101mm) diameter chrome plated angle bars with internal air shut off valve design
